Great as spare part
for scales or for commercial, industrial and experimental
purpose. It's economical and highly accurate.
For several years, we have manufactured load cells for our
scales and supplied internationally for other businesses and
manufacturers.
|
Capacity |
30kg |
Temperature effect on span (%FS/10℃) |
0.014 |
|
Rated Output (mV/V) |
2.0+0.2 |
Temperature effect on zero( %FS/10℃) |
0.017 |
|
Combined Error (%FS) |
0.02 |
Temperature, compensated(℃) |
-10--+40 |
|
Non-linearity (%FS) |
0.017 |
Temperature, operating(℃) |
-35--+65 |
|
Non-repeatability (%FS) |
0.01 |
Excitation, recommended(V) |
5---12(DC) |
|
Creep (%FS/30min) |
0.015 |
Excitation,permition(V) |
18(DC) |
|
Input Resistance(Ω) |
409+6 OR 1060+15 |
Safe Overload(%FS) |
150 |
|
Output Resistance(Ω) |
350+3 OR 1000+5 |
Ultimate Overload(%FS) |
300 |
|
Insulation Resistance(MΩ) |
≥5000(50VDC) |
Protection Class |
IP65 |
|
Zero Balance (%FS) |
2.0 |
Cable Length (m) |
0.4(￠3.8mm) |
