Great as spare part
for scales or for commercial, industrial and experimental
purpose. It's economical and highly accurate.
For several years, we have manufactured load cells for our
scales and supplied internationally for other businesses and
manufacturers.
|
Rated
Capacity: |
(Kg) |
50 |
|
Rated Output: |
(mv/v) |
2.0±0.10% |
|
Zero Balance: |
(%R.O.) |
±2 |
|
Non-linearity: |
(%R.O.) |
±0.02 |
|
Non-repeatability: |
(%R.O.) |
±0.015 |
|
Hysteresis: |
(%R.O.) |
±0.02 |
|
Creep: |
(%R.O./5min) |
±0.02 |
|
Temperature Effect on Zero |
(%R.O./10℃) |
0.03 |
|
Temperature Effect on Output |
%R.O./10℃) |
0.03 |
|
Input Resistance: |
(Ω) |
1130 |
|
Output Resistance: |
(Ω) |
1000 |
|
Insulation Resistance: |
(MΩ) |
≥5000 |
|
Recommended excitation voltage: |
(V) |
5 to 12(DC) |
|
Operating temperature range: |
(℃) |
–10 to +40 |
|
Safe Overload: |
(% R.C.) |
150 |
